LX 700
Six years in planning and development, the LX700 is the direct result of customer feedback for numerous features, capabilities, and performance requests. Designed to enable high flexibility and expandability, the LX700 provides a highly cost effective solution to a wide variety of applications.
Today, everyone wants more for less. Consumers want less costly products that deliver greater functionality. Likewise,
instrumentation products must offer greater value and capabilities for today's demanding markets.
The LX700 system was designed to be highly generalized to cover many measurement application market segments including both lab R&D and production QC/QA testing. The software includes a Macro programming script capability to enable users to create custom automated test programs for production line testing.
The module family will be expanded over time and will include: analog, digital, and mixed mode measurements, analog/digital automation control, signal multiplexers, spectrum analyzers, signal generators, impedance analyzers, amplifiers, various metering, and DSP development tools. Numerous measurements can be performed including spectral analysis, distortion analysis, arbitrary waveform and signal generation, and much more.
Features
Modular System
User Configurable
User Expandable
High Density Design
Cost Effective Design
Multiple Mainframe Support
7 Module Bays per Mainframe
High Speed 32bit Internal Bus
Ethernet Computer Interface
USB Computer Interface
GPIB/IEEE-488 Interface
Large Scale Array Measurement
Windowsฎ Application Software
Application Specific Features
Worldwide Operation 85-265VAC
Portable Operation 24VDC
2 Rack Space Chassis
Lightweight 12lb Chassis
Efficient Design & Construction
