Encoder Technology is your best source for the supply, repairs and replacements of all types of encoders. We have a vast amount of knowledge about rotary encoders, shaft encoders, absolute encoders and many more special encoder designs.
Choosing the right encoder for the job can be tedious. That’s why you
need a specialist – who’s seen it all – and will work with you to understand your specific problem and quickly recommend the best solution for your needs. Whether that is for an absolute, incremental or special design rotary or shaft encoder, we have a vast range of products from the biggest names in the industry.
What we can do for you:
Avoid costly mistakes when selecting your Encoder, let us do the work for you! - Select from the Best Source for - Rotary Encoders, Hollow & Shaft Encoders, Incremental & Absolute Encoders, Linear Scales, Resolvers and Accessories. - We can help you to find - Multi-turn or Single-turn Absolute Encoders, SSI, EnDat, Field Bus, Programmable. - Need the latest Encoder Designs? Custom Built, High Accuracy or low cost, just - Call or email us - Need Technical Help or Info? Fast response and Expert Help - Want a Special Encoder? No Problem! - Intrinsically Safe (NAMUR), ATEX Certified, Oil Patch Applications, Heavy Duty, Micro Miniature, Analog Output.
We supply, replace and repair encoders by the biggest names out there. Our products and knowledge ranges across all the big name companies. We can supply, replace and repair an extremely wide range of absolute, incremental and special design rotary or shaft encoders and many other options from:
BEI, Litton, Hohner, Fanuc, Tamagawa, Kuroda, Nikon, Sumtak, Bosch, Dynapar, CUI, Heidenhain, Siemens, AMI, Allen Bradley, Hengstler, Muirhead Vatric, Gaebridge, TWK, PLUS many others
We can be your supplier for products by: TWK, HEIDENHAIN, NEMICON, TAMAGAWA, MTL, MicroTech, RELIANCE ENCODERS.
Highlights
very compact construction for use in harsh conditions
permissible bearing loads similar to our “big encoders”
up to IP67 all around
Hall effect based signal generation
Product details
Flange Synchro flange
Resolution up to 1024 PPR
Housing Ø 24 mm,
L 41 mm
Shaft Ø 6 mm,
L 12 mm
Max. operating speed 12.000 rpm
Permitted load on shaft end max. 80 N radial
max. 50 N axial
Output circuit HTL,
TTL, RS422 compatible
Output channels AB, ABN and inverted signals
Max. pulse frequency 200 kHz
Power supply 4,75 VDC up to 5,5 VDC
5 VDC up to 30 VDC
10 VDC up to 30 VDC
max. 40 mA
Operating temperature -40 °C up to +80 °C
Protection rating IP65 all around,
(Option: IP67 all around)
